The Pilot-RC smoke pump is designed to be easy to install and even easier to setup. Follow the basic steps described below and start churning out billows of smoke in no time!
Choose between continuous smoke or intermittent smoke, both at any desired flow, so no matter what design you want, we have you covered.
| Tailslide Exclusives | No |
|---|
Write Your Own Review
Installation:
The smoke pump comes with just two wires:
- Futaba connector for signal – Connect to your receiver or powerbox to the output that you will be using to control the on/off position as well as the flow.
- XT60 connector for power – Connect a 2S lipo to the power input (voltage input 6.8v-13.0v)
We do not recommend joining both sets of positive and negative wires in order to pull power directly from the receiver or powerbox! - Connect the pump nipples to the smoke tank and exhaust tubes, taking especial notice of the direction of flow, indicated on the pump with an engraved arrow.
Setup:
All setup is done via the radio, using a single channel:
- -100% to -30% radio signal, the pump is ON with an intermittent smoke flow. The higher the % the more fuel flow.
- -30% to +30% radio signal (channel center) the pump is OFF
- +30% to +100% radio signal, the pump is ON with a continuous smoke flow. The higher the % the more fuel flow
