Pilot RC Skywolf 73" V2

As low as $699.99

A true aeromodel, designed for pure fun and simplicity.  From slow flight to fun-fly and even some 3D, this is a surprisingly capable acrobatic model.  Designed by Jan Spatny from Czech Republic.



- +
Availability:In stock
Only %1 left
SKU
P-WOLF-73
Flat Rate Shipping: $175.00

FEATURES:



  • Strong yet light weight design, good for aerobatic flying and can even hover!
  • Highly prefabricated, experienced builders can have air ready in under a day
  • Pre-installed hinges on ailerons, flaps and rudder (glued and sealed)
  • Internally mounted cowling – so no external screws exposed
  • Removable wings with quick release system
  • Laser engraved motor mounting position
  • Open construction allows for easy canister installation for 20-38cc size engine
  • Quick release front windshield / top-hatch, allowing easy access to replace batteries in electric setups
  • Big 5″ wheels
More Information
Tailslide Exclusives Yes
Included Hardware
  • Complete air frame with all basic accessories (such as carbon fibre undercarriage, tail-gear assembly and wing-tubes as well as fibreglass control horns and wheel pants)
  • Pre-installed hinges and pre-mounted canopy
  • Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve
  • Wheels and wheel axels
  • Pre-prepared pushrods with ball links
  • Matching carbon spinner
Required Hardware



Motor: 20-40cc or equivalent electric

Servos: 7 high torque plus throttle // Uses x1 per aileron, x1 per flap, x1 per elevator and x1 on rudder

Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories.

Pilot-Rc recommended hardware:

Write Your Own Review
You're reviewing:Pilot RC Skywolf 73" V2
Model: Sky-Wolf
Wingspan: 73″ (1.850mm)
Length: 62″ (1.580mm)
Wing area: 963 “² (6,214 cm²)
Weight: 12.3 lbs (5.57kg)

Build information

COWL SIZE:

A: 187mm, B: 180mm, C: 190mm, D: 170mm

EXHAUST TUNNEL SIZE:

A: 453mm, B: 64mm, C: 453mm, D: 72mm, E: 132mm, F: 153mm

RUDDER HORNS AND PULL PULL LOCATION:

A: N/A, B: N/A, C: N/A, D: 21mm, E: N/A

Extension wire lengths:

Throttle:
25cm

Each wing:
Flap 0cm
Aileron 40cm
(to reach receiver direct)

Each elevator:
60cm

Each rudder servo:
70cm


CENTER OF GRAVITY:

116mm
Measured back from leading edge of the wing at the fuselage.

You will find a laser engraved C.G. emblem on the inside of the fuselage, located close to the wing tube, which also shows the exact location for Center of Gravity.
