Pilot RC Extra NG 67"
As low as
$499.99
Availability:In stock
Only %1 left
SKU
P-EXNG-67"
Flat Rate Shipping: $125.00
Features
- NEW! Hybrid construction from wood and composite materials for specially reinforced fuselage and wings
- NEW! Patented quick assembly system for wings
- NEW! Patented quick assembly system for canopy. Especially useful for electric version, fast battery changes
- NEW! Patented quick assembly system for SFG
- Strong yet light weight design, especially developed for precision aerobatic and extreme 3D flying
- Highly prefabricated, experienced builders can have air ready in under a day
- Removable wings
- Laser engraved motor mounting position
- Designed for both 20cc engine or electric motor
- Internally mounted cowling – so no external screws exposed
- Included servo extension wires and wing bags
- Push pull rudder link for more precise and direct response
A brand new design, built from a classic. In 2019 Extra Acrobatic Aircraft unveiled their latest masterpiece, and now in 2020 Pilot-RC is unveiling ours.
The Extra NG is the latest iteration of the Extra family, each version becoming more precise and more agile than ever before, and this feeds down all the way through our models.
This new design, combined with all of Pilot-RC’s latest build innovations and methods provide a high quality kit that can be built within minutes upon arrival at the flying field and relied upon for strength, agility and all round fun.
| Tailslide Exclusives | No |
|---|---|
| Included Hardware |
|
| Required Hardware |
*Please note that the setup of this plane allows both electric or gas engines, however in order to use a gas engine, the firewall and engine box must be reinforced.
*Please note that the servo slots are designed to accept a medium size servo (35mm x 15mm) however the wood has been prepared and marked, should you wish to enlarge in order to accept standard size servos. Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories. |
Write Your Own Review
Model: Extra NG
Wingspan: 67″ (1.702mm)
Length: 65.4″ (1.661mm)
Wing area: 872 “² (5,632 cm²)
Weight: 8.1lbs (3.7kg)
Build information
COWL SIZE:
A: 145mm, B: 215mm, C: 225mm, D: 202mm
EXHAUST TUNNEL SIZE:
A: 183mm, B: 68mm, C: 183mm, D: 76mm, E: 110mm, F: 143mm
RUDDER HORNS AND PULL PULL LOCATION:
A: mm, B: mm, C: N/A, D: mm
Extension wire lengths:
Throttle:
No extension required
Each aileron:
10cm
(to reach receiver direct)
Elevator:
70cm
Rudder:
70cm
CENTER OF GRAVITY:
132mm
Measured back from leading edge of the wing at the fuselage.
You will find a laser engraved C.G. emblem on the inside of the fuselage, located close to the wing tube, which also shows the exact location for Center of Gravity.
