iESC 65.8 PBS-5105
$166.00
The iESC is based on the latest generation of controllers for brushless
motors, with a 32-Bit processor and expanded functions such as telemetry
and the ability to adjust settings directly from the transmitter.
Availability:In stock
SKU
iESC 65.8
- High-performance brushless speed controller with 32-bit technology
- Latest generation of MosFets for reduced power loss and maximum
possible reliability - Telemetry for PowerBox, Jeti and Futaba radio control systems
- Fixed-wing and Helicopter modes
- Adjustable direction of rotation, timing, battery type, freewheel, start-up
current and other parameters - Adjustable regulatory parameters in helicopter mode
- Parameters directly adjustable from PowerBox and Jeti transmitters
- Parameters adjustable using LCD programming device for all systems
- 8A BEC
- Power-on self-test checks motor, throttle position and voltage
- Ingenious case design ensures optimum cooling
The iESC is based on the latest generation of controllers for brushless motors, with a 32-bit processor and expanded functions such as telemetry and the ability to adjust settings directly from the transmitter.
The high-performance micro-processor ensures smooth running for brushless motors with up to 40 poles.
Brake power, motor timing, direction of rotation, BEC output voltage, freewheel, helicopter mode and much more can be adjusted directly from a PowerBox or Jeti transmitter. This means that set-up boxes and plug-in jumper cards are now a thing of the past.
| Tailslide Exclusives | No |
|---|
Write Your Own Review
| Operating voltage | 3s - 6s |
| Maximum load current | 65A/75A Continous/Peak |
| Output voltage | 6.0V/7.4V/8.4V BEC |
| Signal input | PWM |
| Supported RC systems | PowerBox, Jeti, Futaba, others without telemetry |
| Supported telemetry systems | P²-BUS, EX-BUS, S.BUS2 |
| Dimensions | 60 x 36 x 20 mm |
| Weight | 72g |
| Temperature range | -20°C to +85°C |
